Automatic Seam Welding Machine
Automatic Seam Welding Machine
Can Body Welder, Accessories & Seam Protection Layer Curing Systems – Induction Curing Oven
Continuous production. Absolute precision. Full control.
- Umar's modular curing systems harden lacquer or powder seam protection immediately after application, ensuring strong adhesion and consistent seam quality.
- Available in gas or induction versions, with linear or U-shape layouts, the system includes automatic temperature control and speed-adjustable conveyor belts for flexible integration.
- Rare-earth magnetic induction coils deliver stable, uniform curing with long service life. Dual-side SPWM pulse control ensures reliable operation independent of main power fluctuations.
- Smart heating activates only when can bodies are detected, reducing energy consumption and eliminating unnecessary heat loss.
- No water cooling is required, minimizing condensate and maintenance.
- A powerful exhaust system keeps the workshop clean, while PLC-controlled HMI enables precise digital control. Optional intelligent temperature regulation and customized transport systems are available for specific production needs.
Technical Data
| Model | Capacity (m/min.*) | Body Diameter (mm) | Heating Options |
|---|---|---|---|
| MAC 35234 | 9 – 25 | Ø73 – 300 | LPG / Natural Gas / Induction |
* Varies depending on welder speed. Oven length and number of heaters can be reduced on demand.
Automatic Seam Welding Machine
Continuous production. Absolute precision. Full control.
- Fully automatic machine is developed for giving cylindrical shape and seam welding operation of three-piece can bodies.
- Switch to different diameters in a minimum time with convenient easy-changeover calibration unit.
- Easy maintenance and practical adjustment.
- Comprehensive access via PLC.
- Monitor production remotely from all smart devices.
- Online service plus software updates from anywhere.
Technical Data
| Model | Capacity (bodies/min.*) | Body Diameter (mm) | Body Height (mm) | Tinplate Thickness (mm) | Copper Wire Dia. (mm) | Welding Speed (m/min.*) |
|---|---|---|---|---|---|---|
| MAC 20655 | 60 | Ø140 – 300 | 100 – 530 | 0.2 – 0.4 | Ø1.38 – 1.50 | 9 – 25 |
| MAC 20640 | 80 | Ø140 – 300 | 100 – 400 | 0.2 – 0.4 | Ø1.38 – 1.50 | 9 – 25 |
| MAC 20332 (Non-Stop) | 120 | Ø73 – 165 | 50 – 165 | 0.2 – 0.3 | Ø1.38 – 1.50 | 9 – 25 |
* Output speed varies depending on can body dimensions and operations selected.
